Steel grating is available in varied forms suitable for different applications and overall load conditions. Hot dip galvanizing or painting provides excellent appearance, durability, and enhanced economy. Galvanized steel grating is widely used in power stations, chemical industry, oil & gas industry, boiler plants, mining, refineries, and more.
30mm Pitch Grating: The most widely used type in industrial fields with the strongest resistance to surface lash.
40mm Pitch Grating: The most economical and lightest type, ideal for applications with small spans.
60mm Pitch Grating: Developed specifically for the mining industry to solve mineral splash problems on plates.
30/76mm Pitch Grating: The most popular type used domestically and internationally, suitable for walkways, platforms, and many other applications.
| Parameter | Available Options |
|---|---|
| Bearing Bar Height (mm) | 20/25/30/32/35/40/44/45/50/90/95/100, etc. |
| Bearing Bar Thickness (mm) | 3/5/10, etc. |
| Bearing Bar Pitch (mm) | 20/25/30/31/32.5/33/34/40/41/43/50, etc. |
| Cross Bar Pitch (mm) | 30/38/50/66/100, etc. |
| Surface Treatment | Hot dip galvanized/Painted |
| Note | Sizes can be customized - please contact us |
You can also purchase from our factory:
We also offer customization and purchase of products such as wire mesh, punched plates, and steel plates.
Steel grating is widely used in construction, oil and gas, chemical plants, power stations, shipbuilding, mining, wastewater treatment, food processing, and transportation industries.
The correct specification depends on load requirements, span length, environment, surface treatment, and application type. Factors such as bearing bar size, spacing, and thickness should also be considered.
Common steel grating panel sizes include 1000×6000 mm and 1000×5800 mm, but customized dimensions are available according to project requirements.
Steel grating can be untreated, painted, powder coated, or hot-dip galvanized. Hot-dip galvanizing is the most popular option for corrosion protection.
Yes. Hot-dip galvanized or stainless steel grating performs very well outdoors because of its excellent weather and corrosion resistance.
Serrated grating features toothed bearing bars for enhanced slip resistance, making it ideal for wet or oily environments. Plain grating has a smooth surface and is commonly used in standard industrial applications.
